| TypeForm | Input phase |
Voltage class [V] |
Capacity [kW] |
W [mm] |
H [mm] |
D [mm] |
W1 [mm] |
H1 [mm] |
D2 [mm] |
H2 [mm] |
Weight [kg] |
| VFPS1-2004PL | 3 | 200 | 0.4 | 130 | 230 | 152 | 114 | 220 | 0 | 0 | 3 |
| VFPS1-2007PL | 3 | 200 | 0.75 | 130 | 230 | 152 | 114 | 220 | 0 | 0 | 3 |
| VFPS1-2015PL | 3 | 200 | 1.5 | 130 | 230 | 152 | 114 | 220 | 0 | 0 | 3 |
| VFPS1-2022PL | 3 | 200 | 2.2 | 155 | 260 | 164 | 138 | 249 | 0 | 0 | 4 |
| VFPS1-2037PL | 3 | 200 | 3.7 | 155 | 260 | 164 | 138 | 249 | 0 | 0 | 4 |
| VFPS1-2055PL | 3 | 200 | 5.5 | 175 | 295 | 164 | 158 | 283 | 0 | 0 | 5.5 |
| VFPS1-2075PL | 3 | 200 | 7.5 | 210 | 295 | 191 | 190 | 283 | 0 | 0 | 7.5 |
| VFPS1-2110PM | 3 | 200 | 11 | 230 | 400 | 191 | 210 | 386 | 0 | 0 | 14 |
| VFPS1-2150PM | 3 | 200 | 15 | 230 | 400 | 191 | 210 | 386 | 0 | 0 | 14 |
| VFPS1-2185PM | 3 | 200 | 18.5 | 240 | 420 | 212 | 206 | 403 | 0 | 0 | 21 |
| VFPS1-2220PM | 3 | 200 | 22 | 240 | 420 | 212 | 206 | 403 | 0 | 0 | 21 |
| VFPS1-2300PM | 3 | 200 | 30 | 320 | 550 | 242 | 280 | 525 | 0 | 0 | 41 |
| VFPS1-2370PM | 3 | 200 | 37 | 320 | 550 | 242 | 280 | 525 | 0 | 0 | 41 |
| VFPS1-2450PM | 3 | 200 | 45 | 320 | 550 | 242 | 280 | 525 | 0 | 0 | 41 |
| VFPS1-2550P | 3 | 200 | 55 | 310 | 920 | 370 | 250 | 650 | 5 | 0 | 87 |
| VFPS1-2750P | 3 | 200 | 75 | 310 | 920 | 370 | 250 | 650 | 5 | 0 | 87 |
| VFPS1-2900P | 3 | 200 | 90 | 350 | 1022 | 370 | 298 | 758 | 5 | 0 | 103 |
| VFPS1-4007PL | 3 | 400 | 0.75 | 130 | 230 | 152 | 114 | 220 | 0 | 0 | 3 |
| VFPS1-4015PL | 3 | 400 | 1.5 | 130 | 230 | 152 | 114 | 220 | 0 | 0 | 3 |
| VFPS1-4022PL | 3 | 400 | 2.2 | 130 | 230 | 152 | 114 | 220 | 0 | 0 | 3 |
| VFPS1-4037PL | 3 | 400 | 3.7 | 155 | 260 | 164 | 138 | 249 | 0 | 0 | 4 |
| VFPS1-4055PL | 3 | 400 | 5.5 | 175 | 295 | 164 | 158 | 283 | 0 | 0 | 5.5 |
| VFPS1-4075PL | 3 | 400 | 7.5 | 175 | 295 | 164 | 158 | 283 | 0 | 0 | 5.5 |
| VFPS1-4110PL | 3 | 400 | 11 | 210 | 295 | 191 | 190 | 283 | 0 | 0 | 8 |
| VFPS1-4150PL | 3 | 400 | 15 | 230 | 400 | 191 | 210 | 386 | 0 | 0 | 13 |
| VFPS1-4185PL | 3 | 400 | 18.5 | 230 | 400 | 191 | 210 | 386 | 0 | 0 | 16 |
| VFPS1-4220PL | 3 | 400 | 22 | 240 | 420 | 212 | 206 | 403 | 0 | 0 | 21 |
| VFPS1-4300PL | 3 | 400 | 30 | 240 | 550 | 242 | 206 | 529 | 0 | 0 | 29 |
| VFPS1-4370PL | 3 | 400 | 37 | 240 | 550 | 242 | 206 | 529 | 0 | 0 | 29 |
| VFPS1-4450PL | 3 | 400 | 45 | 320 | 630 | 290 | 280 | 605 | 5 | 0 | 48 |
| VFPS1-4550PL | 3 | 400 | 55 | 320 | 630 | 290 | 280 | 605 | 5 | 0 | 48 |
| VFPS1-4750PL | 3 | 400 | 75 | 320 | 630 | 290 | 280 | 605 | 5 | 0 | 48 |
| VFPS1-4900PC | 3 | 400 | 90 | 310 | 920 | 370 | 250 | 650 | 5 | 0 | 89 |
| VFPS1-4110KPC | 3 | 400 | 110 | 310 | 920 | 370 | 250 | 650 | 5 | 0 | 89 |
| VFPS1-4132KPC | 3 | 400 | 132 | 350 | 1022 | 370 | 298 | 758 | 5 | 0 | 108 |
| VFPS1-4160KPC | 3 | 400 | 160 | 330 | 1190 | 370 | 285 | 920 | 7 | 0 | 118 |
| VFPS1-4220KPC | 3 | 400 | 220 | 430 | 1190 | 370 | 350 | 920 | 7 | 0 | 161 |
| VFPS1-4250KPC | 3 | 400 | 250 | 585 | 1190 | 370 | 540 | 920 | 7 | 0 | 194 |
| VFPS1-4280KPC | 3 | 400 | 280 | 585 | 1190 | 370 | 540 | 920 | 7 | 0 | 204 |
| VFPS1-43１5KPC | 3 | 400 | 315 | 585 | 1190 | 370 | 540 | 920 | 7 | 0 | 204 |
| VFPS1-4400KPC | 3 | 400 | 400 | 880 | 1390 | 370 | 418 | 1120 | 7 | 0 | 302 |
| VFPS1-4500KPC | 3 | 400 | 500 | 880 | 1390 | 370 | 418 | 1120 | 7 | 0 | 370 |
| VFPS1-4630KPC | 3 | 400 | 630 | 1108 | 1390 | 370 | 533 | 1120 | 7 | 0 | 462 |
