| TypeForm | Input phase |
Voltage class [V] |
Capacity [kW] |
W [mm] |
H [mm] |
D [mm] |
W1 [mm] |
H1 [mm] |
D2 [mm] |
H2 [mm] |
Weight [kg] |
| VFMB1S-2002PL | 1 | 240 | 0.2 | 45 | 270 | 232 | 29 | 258 | 0 | 47 | 1.7 |
| VFMB1S-2004PL | 1 | 240 | 0.4 | 45 | 270 | 232 | 29 | 258 | 0 | 47 | 1.7 |
| VFMB1S-2007PL | 1 | 240 | 0.75 | 45 | 270 | 232 | 29 | 258 | 0 | 47 | 1.8 |
| VFMB1S-2015PL | 1 | 240 | 1.5 | 60 | 270 | 232 | 42 | 258 | 0 | 47 | 2.1 |
| VFMB1S-2022PL | 1 | 240 | 2.2 | 60 | 270 | 232 | 42 | 258 | 0 | 47 | 2.2 |
| VFMB1-4004PL | 3 | 500 | 0.4 | 45 | 270 | 232 | 29 | 258 | 0 | 47 | 1.8 |
| VFMB1-4007PL | 3 | 500 | 0.75 | 45 | 270 | 232 | 29 | 258 | 0 | 47 | 1.9 |
| VFMB1-4015PL | 3 | 500 | 1.5 | 45 | 270 | 232 | 29 | 258 | 0 | 47 | 1.9 |
| VFMB1-4022PL | 3 | 500 | 2.2 | 60 | 270 | 232 | 42 | 258 | 0 | 47 | 2.2 |
| VFMB1-4037PL | 3 | 500 | 4.0 | 60 | 270 | 232 | 42 | 258 | 0 | 47 | 2.4 |
| VFMB1-4055PL | 3 | 500 | 5.5 | 150 | 220 | 232 | 130 | 210 | 0 | 12 | 4.3 |
| VFMB1-4075PL | 3 | 500 | 7.5 | 150 | 220 | 232 | 130 | 210 | 0 | 12 | 4.3 |
| VFMB1-4110PL | 3 | 500 | 11 | 180 | 310 | 232 | 160 | 295 | 0 | 20 | 6.8 |
| VFMB1-4150PL | 3 | 500 | 15 | 180 | 310 | 232 | 160 | 295 | 0 | 20 | 6.9 |
 Each dimention means above figure. (ex. VFMB1-4022PL) |
|||||||||||
